Alignment |
Push-Pull, acoustic suspension |
Amplifer |
1.3kW rms short term |
Display Interface |
2.4” LCD color touchscreen |
App |
iOS and Android |
Processor |
32-bit ARM Cortex M4, double precision floating point math |
DSP Engine |
Ti DSP 48-bit data paths |
Driver compliment |
(2)300mm, Glass fiber diaprhragm +/-20mm linear excursion |
Frequency Response |
THX EQ 20-256Hz (-6dB) / 16-278Hz (-10dB) Boost (Large Room) EQ 16-256Hz (-6dB) / 14-278Hz (-10dB) Cut (Small Room) EQ 25-256Hz (-6dB) / 19-278Hz (-10dB)) |
Inputs |
(2) Balanced XLR (2) Unbalanced RCA |
Outputs |
(2) Balanced XLR unbuffered (2) Unbalanced RCA unbuffered |
Parametric EQ |
10-Band PEQ with 3 user presets |
Low Pass filter |
Bypass, 30-160Hz, slope 6,12,18,24dB/oct |
Phase |
Variable 0-270° |
Polarity |
Normal / inverted |
Configurable Auto turn-on and 12v Trigger |
XLR 1, XLR 1+2, RCA 1, RCA 1+2 |
Dimensions (HxWxD) |
600 x 410 x 500mm 23.6 x 16.1 x 19.7” |
Weight |
48.2 kg (106.0 lbs.) |
Certification |
THX Dominus (2), THX Ultra (1) |
Available finishes |
Piano black |
